"Tekhnichna Diahnostyka ta Neruinivnyi Kontrol" (Technical Diagnostics and Non-Destructive Testing) #2, 2026, pp. 13-16

Infrared termography of solar cells with a thermogenerating layer based on varizone semiconductors

V.O. Storozhenko, O.V. Miahkyi, R.P. Orel, S.M. Meshkov

RTC «Thermocontrol» of Kharkiv National University of Radio Electronics. 14 Nauky Ave., 61166, Kharkiv, Ukraine. E-mail: roman.orel@nure.ua

This study investigates the potential application of infrared thermography for integrity testing of modern solar cells with an additional thermogenerating layer based on varizone semiconductors (in particular, Si-Ge solid solutions). A comprehensive thermoelectric model of a multilayer structure has been developed and analysed, combining classical thermophysical equations with thermoelectric models of charge geion and transport in a varizone structure. Unlike standard approaches, the model accounts for the fact that the formation of a temperature signal from a defect is caused not only by a local change in thermophysical characteristics but also by a deterioration in heat dissipation due to the suppression (discontinuation) of charge carrier generation in the damaged zone. A classification of the main technological and operational defects is proposed, among which foreign inclusions (SiO2 or Si impurities), thinning of the generating layer, and local thermal breakdown are identified. Through numerical modeling (using finite difference and finite element methods), quantitative parameters of the detectable signal in the form of a temperature contrast on the object’s surface were established. It was shown that the magnitude of the temperature signal significantly depends on the type of defect: from fractions of a degree for local inclusions to tens of degrees in the case of thermal breakdown. The results show that the sensitivity of modern thermal imaging systems is sufficient for the reliable identification of the considered types of structural defects. It is noted that existing methods for suppressing interference can be applied to reduce the impact of interference on defect detection. Thus, the effectiveness of thermal inspection for the defect detection of solar panels with a thermogenerating layer is demonstrated. 12 Ref., 4 Fig.
Keywords: infrared thermography, solar panels, thermoelectric model, varizone semiconductors, generation defects

Received: 20.04.2026
Received in revised form: 28.05.2026
Accepted: 10.06.2026
Posted online: 30.06.2026

References

1. Maldague, Xavier P.V. (2001) Theory and practice of infrared technology for nondestructive testing. New York: John Wiley & Sons, Inc.
2. Saidov, A., Leyderman, A.Y., Karshiev, A.B. (2019) Photothermovoltaic effect in a Si1-xGex variband solid solution. Applied Solar Energy, 55(1), 12–17. DOI: https://doi.org/10.3103/S0003701X19010122
3. Saidov, A.S., Usmonov, S.N., Saparov, D.V. (2019) Structural studies of the epitaxial layer of a substitutional solid solution (GaAs)1−x(ZnSe)x with nanocrystals. Advances in Mater. Sci. and Engineering, 2019, 195, 3932195. DOI: https://doi.org/10.1155/2019/3932195
4. Saidov, A.S., Leyderman, A.Yu., Karshiev, A.B. (2016) The thermovoltaic effect in variband solid Si1-xGex (0≤x≤1). Technical Physics Letters, 42(7), 725–728. DOI: https://doi.org/10.1134/S1063785016070270
5. Saidov, A.S., Leiderman, A.Yu. (2015) Electrophysical and optical properties of silicon produced by multiple remelting of metallurgical silicon by concentrated solar beams (Review). Applied Solar Energy, 51(3), 183–194. DOI: https://doi.org/10.3103/S0003701X1503010X
6. Saidov, A.S, Usmonov, S.N., Asatova, U.P. (2012) Growth of Ge1–xSnx solid solution films and study of their structural properties and some of their photoelectric properties. Semiconductors, 46, 1088–1095. DOI: https://doi.org/10.1134/S1063782612080180
7. Saidov, A.S., Usmonov, S.N., Saidov, M.S. (2015) Liquid-phase epitaxy of the (Si2)1−x−y(Ge2)x(GaAs) y substitutional solid solution (0≤x≤0.91, 0≤y≤0.94) and their electrophysical properties. Semiconductors, 49(4), 547–550. DOI: https://doi.org/10.1134/S106378261504020X
8. Storozhenko, V., Myagkiy, A., Orel, R. (2016) Optimization of the procedure for thermal flaw detection in honeycomb structures by improving the accuracy of the interference function. Eastern-European J. of Enterprise Technologies, 5/5(83), 12–18. DOI: https://doi.org/10.15587/1729-4061.2016.79563
9. Aziz, A. (2009) A similarity solution for laminar thermal boundary layer over a flat plate with a convective surface boundary condition. Commun. Nonlinear Sci. Numer. Simulat., 14, 1064–1068. DOI: https://doi.org/10.1016/j.cnsns.2008.05.003
10. Pidkopai, V.M., Hanzha, A.M., Marchenko, N.A. (2014) Mathematical simulation and identification of actual heat losses caused by the damaged insulation of the pipelines of heating mains. Visnyk NTU «KhPI»: Zbirnyk Naukovykh Prats. Seriшa: Enerhetychni ta Teplotekhnichni Protsesy y Ustatkuvannia, 12(1055), 83–89 [in Ukrainian]. https://repository.kpi.kharkov.ua/handle/KhPI-Press/8979
11. Miahkyi, O.V., Orel, R.P., Meshkov, S.M., Storozhenko, V.O. (2024) Ways to increase the EMF of semiconductor elements based on thermoelectric effects. Radiotekhnika, 216, 103–107 [in Ukrainian]. DOI: https://doi.org/10.30837/rt.2024.1.216.10
12. Storozhenko, V.O., Miahkyi, O.V., Meshkov, S.M., Orel, R.P. (2025) Application of wavelet analysis and differential-integral graphical methods for thermogram processing in thermal nondestructive testing. Technical Diagnostics and Nondestructive Testing, 2, 18–22. DOI: https://doi.org/10.37434/tdnk2025.02.03

---

This article is licensed under a Creative Commons Attribution-NonCommercial-NoDerivatives 4.0 International License.

---

Suggested Citation

ВV.O. Storozhenko, O.V. Miahkyi, R.P. Orel, S.M. Meshkov (2026) Infrared termography of solar cells with a thermogenerating layer based on varizone semiconductors. Technical Diagnostics and Non-Destructive Testing, 02, 13-16. https://doi.org/10.37434/tdnk2026.02.02
