The Paton Welding Journal, 2025, #4, 27-36 pages

Electron beam welding of gas valve elements from Mo‒Ti‒Zr alloy

V.I. Zagornikov, V.M. Nesterenkov, K.S. Khripko, O.N. Ignatusha

E.O. Paton Electric Welding Institute of the NASU. 11 Kazymyr Malevych Str., 03150, Kyiv, Ukraine. E-mail: zagornikov@technobeam.com.ua

Abstract
The technological techniques of electron beam welding (EBW) are considered, the application of which would allow obtaining the required quality of joints of gas valve parts made of Mo‒Ti‒Zr (TZM) alloy, which is used in difficult conditions of the nuclear industry. It is known that in order to produce a welded joint with relatively high ductility indices, the oxygen content should not exceed thousandths of a percent. Alloys produced by vacuum arc and electron beam melting are used for welded structures. They have a much lower tendency to form porosity in welded joints than similar alloys made by powder metallurgy methods. Such alloys can be welded, but these joints cannot always be used under dynamic loads. When choosing the optimal welding technique for gas valve parts, technical requirements for edge preparation, quality of welded joints, availability of appropriate equipment and technological tooling were taken into account. The problems of assembly and subsequent welding of gas valve parts made of Mo‒Ti‒Zr (TZM) alloy revealed during the investigations caused the need in changing design of the joints. As a result, a scheme for welding gas valve parts was proposed, which uses flanging of weld butt edges. This led to optimizing the penetration shape. The proposed welding parameters and flange geometry made it possible to lower the degree of saturation of the weld metal with gases due to the reduction in the penetration depth under the conditions of rapid heat removal and, as a result, to produce sufficiently high-quality welded joints. In addition, with all the variety of technological techniques used during the investigations, the priority of the correctly selected design of the circumferential butt and the accuracy of the welding assembly was proven.
Keywords: Mo‒Ti‒Zr (TZM) alloy, electron beam welding (EBW), microstructure, porosity, gas valve, flanging of welded edges

Received: 20.06.2024
Received in revised form: 25.10.2024
Accepted: 09.05.2025

References

1. Trefilov, V.I., Milman, Yu.V., Firstov, S.A. (1975) Physical basis of the strength of refractory metals. Kyiv, Naukova Dumka [in Russian].
2. Platte, W.N. (1956) Influence of oxygen on soundness and ductility of molybdenum weld. Weld. J., 35(8), 369–381.
3. Platte, W.N. (1957) Effects of nitrogen on the soundness and ductility of welds in molybdenum Weld. J., 36(6), 301–306.
4. Gurevich, S.M. (1975) Welding of chemically active and refractory metals and alloys. Kyiv, Naukova Dumka [in Russian].
5. Miao-Xia Xie, Yan-Xin Li, Xiang-Tao Shang et al. (2019) Effect of heat input on porosity defects in a fiber laser welded socket-Joint made of powder metallurgy molybdenum alloy. Materials, 12, 1433. DOI: https://doi.org/10.3390/ma12091433 https://www.semanticscholar.org/paper/Effect-of-Heat-Input-on-Porosity-Defects-in-a-Fiber-Xie-Li/ff3980832c812389e46ff4ffb4fe22d56e40a494
6. Zhang, L.J., Liu, J.Z., Pei, J.Y. et al. (2019) Effects of power modulation, multipass remelting and Zr addition upon porosity defects in laser seal welding of end plug to thin-walled molybdenum alloy. J. Manuf. Process., 41, 197–207. DOI: https://doi.org/10.1007/s00170-020-06482-5
7. Xie, M.X., Li, Y.X., Shang, X.T. et al. (2019) Microstructure and mechanical properties of a fiber welded socket-joint made of powder metallurgy molybdenum alloy. Metals, 9, 640. DOI: https://doi.org/10.3390/met9060640
8. Zhang, L.L., Zhang, L.J., Long, J. et al. (2019) Enhanced mechanical performance of fusion zone in laser beam welding joint of molybdenum alloy due to solid carburizing. Mater. Des., 181, 107957. DOI: https://doi.org/10.1016/j.matdes.2019.107957
9. Zhang, L.L., Zhang, L.J., Long, J. et al. (2019) Effects of titanium on grain boundary strength in molybdenum laser weld bead and formation and strengthening mechanisms of brazing layer. Mater. Des., 169, 107681. https://www.sciencedirect. com/science/article/pii/S0264127519301182 https://doi.org/10.1016/j.matdes.2019.107681
10. Mushegyan, V.O. (2009) Electron beam melting of reduced molybdenum concentrate. Advances in Electrometallurgy, 4, 225–228.
11. Krajnikov, A.V., Morito, F., Slyunyaev, V.N. (1997) Impurity-induced embrittlement of heat-affected zone in welded Mo-based alloys. Inter. J. of Refractory Metals and Hard Materials, 15(5–6), 325–339. DOI: https://doi.org/10.1016/S0263-4368(97)87507-5
12. Stütz, M., Oliveira, D., Rüttinger, M. et al. (2016) Electron beam welding of TZM sheets. Mater. Sci. Forum, 879, 1865–1869. DOI: https://doi.org/10.4028/www.scientific.net/MSF.879.1865
13. Korneev, N.I., Pevzner, S.B., Razuvaev, E.I., Skugarev, I.G. (1967) Pressure processing of refractory metals and alloys. Moscow, Metallurgiya [in Russian].
14. Wang Jiteng, Wang Juan, Li Yajiang and Zheng Deshuang (2014) Progress of research on welding for molybdenum alloys. High Temp. Mater. Proc. 33(3), 193 – 200. DOI: https://doi.org/10.1515/htmp-2013-0037
15. https://www.researchgate.net/publication/272570992_Progress_of_Research_on_Welding_for_Molybdenum_Alloys14
16. Skryabinskyi, V.V., Nesterenkov, V.M., Rusynyk, M.O. (2020) Electron beam welding with programming of beam power density distribution. The Paton Welding J., 1, 49–53. DOI: https://doi.org/10.37434/tpwj2020.01.07
17. Kovbasenko, S.N., Yakubovsky, V.V., Ivashchenko, G.A. et al. (1987) Method of electron beam welding of high-strength steels. USSR Cert. 1355411, Int. Cl. 3 V23K 15/00. PWI [in Russian].

---

Suggested Citation

V.I. Zagornikov, V.M. Nesterenkov, K.S. Khripko, O.N. Ignatusha (2025) Electron beam welding of gas valve elements from Mo‒Ti‒Zr alloy. The Paton Welding J., 04, 27-36.

---
